Product Details:
|
| Type: | Geocells | Warranty: | More Than 5 Years |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Project Solution Capability: | Total Solution For Projects |
| Application: | Load Support/Slope Stabilization/Retaining Wall, Road Basement | Design Style: | Industrial |
| Material: | HDPE | Product Name: | Geocell Gravel Grid |
| Color: | Black | Keyword: | Soil Stabilization Geocell Grid |
| Thickness(textured): | 1.0-1.7mm | Welding Distance: | 330mm-1000mm |
| Surface: | Textured Smooth | Package: | Plastic Packing Belts |
| Description: | Textured Perforated Geocell Product | Port: | Qingdao/Shanghai/Tianjin Port |
Product Name | Geocell |
Cell Depth | 50, 75, 100, 125, 150, 200mm |
Weld Spacing | 330, 356, 400, 445, 660, 712mm |
Thickness(Textured) | 1.5, 1.52, 1.6mm |
Thickness(Smooth) | 1.1, 1.2mm |
Colour | Black, Sandy, Green |
Standard | ASTM, ISO |
Cell | Test Method | Units | Values | ||
Material | - | - | Virgin HDPE | ||
ESCR | ASTM D1603 | Hours | 400 | ||
Density | ASTM D1505 | g/cm3 | 0.945-0.960 | ||
Thickness(smooth) | ASTM D5199 | mm | 1.20 (-5% +10%) | ||
Thickness(Textured) | ASTM D5199 | mm | 1.50 (-5% +10%) | ||
Carbon Black | ASTM D1603 | % | ≥ 1.5 | ||
Seam Peel Strength | USACE GL-86-19 | N | ≥ 15KN/m | ||
Tensile Strength at Break | ASTM D638 | KN/m2 | ≥ 32000 (TD) / ≥ 30000 kN (MD) | ||
Elongation at Break | ASTM D6693 | ≥ 900 (TD) / ≥ 480 (MD) | |||
Oxidative Induction Time | ASTM D3895 | min | ≥150 | ||
Long-term Seam Peel Strength | Long term seam peel strength test shall be performed on all resin or pre-manufactured sheet or strips. A 100mm wide seam sample shall support a 72.5kg load for a period of 168 hours minimum in a temperature controlled environment undergoing a temperature change on a 1-hour cycle from 23ºC to 54ºC | ||||
