Product Details:
|
| Type: | Geocells | Warranty: | More Than 5 Years |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Project Solution Capability: | Total Solution For Projects |
| Application: | Load Support/Slope Stabilization/Retaining Wall, Road Basement | Design Style: | Industrial |
| Material: | HDPE | Product Name: | Geocell Gravel Grid |
| Color: | Black | Keyword: | Soil Stabilization Geocell Grid |
| Thickness(textured): | 1.0-1.7mm | Welding Distance: | 330mm-1000mm |
| Surface: | Textured Smooth | Package: | Plastic Packing Belts |
| Description: | Textured Perforated Geocell Product | Port: | Qingdao/Shanghai/Tianjin Port |
|
Product Name
|
Geocell
|
|
Cell Depth
|
50, 75, 100, 125, 150, 200mm
|
|
Weld Spacing
|
330, 356, 400, 445, 660, 712mm
|
|
Thickness(Textured)
|
1.5, 1.52, 1.6mm
|
|
Thickness(Smooth)
|
1.1, 1.2mm
|
|
Colour
|
Black, Sandy, Green
|
|
Standard
|
ASTM, ISO
|
|
Cell
|
Test Method
|
Units
|
Values
|
||
|
Material
|
-
|
-
|
Virgin HDPE
|
||
|
ESCR
|
ASTM D1603
|
Hours
|
400
|
||
|
Density
|
ASTM D1505
|
g/cm3
|
0.945-0.960
|
||
|
Thickness(smooth)
|
ASTM D5199
|
mm
|
1.20 (-5% +10%)
|
||
|
Thickness(Textured)
|
ASTM D5199
|
mm
|
1.50 (-5% +10%)
|
||
|
Carbon Black
|
ASTM D1603
|
%
|
≥ 1.5
|
||
|
Seam Peel Strength
|
USACE GL-86-19
|
N
|
≥ 15KN/m
|
||
|
Tensile Strength at Break
|
ASTM D638
|
KN/m2
|
≥ 32000 (TD) / ≥ 30000 kN (MD)
|
||
|
Elongation at Break
|
ASTM D6693
|
|
≥ 900 (TD) / ≥ 480 (MD)
|
||
|
Oxidative Induction Time
|
ASTM D3895
|
min
|
≥150
|
||
|
Long-term
Seam Peel Strength |
Long term seam peel strength test shall be performed on all resin or pre-manufactured sheet or strips. A 100mm wide seam sample
shall support a 72.5kg load for a period of 168 hours minimum in a temperature controlled environment undergoing a temperature change on a 1-hour cycle from 23ºC to 54ºC |
|
|
||
