Product Details:
|
| Type: | Geomembranes | Warranty: | More Than 5 Years |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Project Solution Capability: | Total Solution For Projects |
| Application: | Fish Pond, Landfill | Design Style: | Industrial |
| Material: | HDPE LDPE LLDPE EPDM EVA | Color: | Black White Green Blue |
| Product Name: | HDPE Geomembrane Liner | Keyword: | HDPE Geomembrane Waterproof |
| Length: | 50-200m | Thickness: | 0.2mm-3mm |
| Width: | 1m~8m | Surface: | Double Smooth |
| Standard: | ASTM GRI-GM13 | Port: | Qingdao/Shanghai/Tianjin Port |
Thickness | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 |
Density g/m2 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 |
Tensile Yield Strength (N/mm) | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
Tensile Breaking Strength(N/mm) | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
Bongation at yield(%) | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 |
Elongation at break(%) | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 |
Tear resistance(N) | ≥93 | ≥125 | ≥160 | ≥190 | ≥250 | ≥315 | ≥375 |
Puncture strength(N) | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
Tensile load stress cracking | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 |
